Submersible slurry pump

Submersible slurry pump

People who are linked to the construction business or work for industries must know the importance of desilter. Desilter is a hydrocyclone that is used to separate the sand particles from each other.

Category:

Contact

DESCRIPTION

Submersible Slurry Water Pump is a vital part of the mud cleaning process. They are primarily used as the oil drilling solids control system but can also be utilized for pumping concentrated liquids and mud. The mud is recycled through the Submersible Slurry Pump, which treats the fluid. They are made to be highly efficient and serve for an extended period. The Submersible Slurry Pump transport solid as well as liquid particles through the pipe, which are then recycled and transported to the other essential pieces of equipment that are part of the mud treatment process. The fluid is input into the geometrically designed components that enable a better flow regime of the medium through the impeller. It also reduces the hydraulic losses which are caused by the impact of local and on-way. The pump flow components have high hard alloy casting for wear and corrosion resistance. This is crucial for the lengthy life span of the Submersible Slurry Pump. Main features of Submersible Slurry Pump
  • Impeller
  • Shaft
  • Motor
  • Wear plate
  • Mechanical Seals
  • Agitator
  • Jetting
  • Replaceable Wear Parts

Technical Parameters of Submersible slurry pump

  Model   Flow(m 3 / h)   Lift(m )   Speed(r/ m in)   Efficiency(%)   Power(KW)
AB5 0 YZ2 0 - 1 8 2 0 1 8 1 4 5 0 4 2 3
AB5 0 YZ4 0 - 1 0 4 0 1 0 .5 1 4 5 0 4 7 4
AB5 0 YZ5 0 - 1 2 6 0 1 0 .8 1 4 5 0 5 5 5 .5
AB8 0 YZ5 0 - 2 0 6 0 1 8 1 4 5 0 4 8 7 .5
AB8 0 YZ8 0 - 2 0 B 8 0 1 3 .4 1 4 5 0 5 1 7 .5
AB8 0 YZ8 0 - 2 0 A 9 0 1 5 1 4 5 0 5 1 1 1
AB1 0 0 YZ1 0 0 - 3 0 1 0 0 3 1 1 4 5 0 5 4 2 2
AB1 0 0 YZ1 0 0 - 3 0 A 1 1 0 2 4 1 4 5 0 5 4 1 8 .5
AB1 0 0 YZ1 6 0 - 3 8 B 1 6 4 2 6 1 4 5 0 5 0 3 0
AB1 5 0 YZ2 5 0 - 4 0 B 2 4 0 2 4 1 4 5 0 5 0 3 7
AB1 5 0 YZ2 5 0 - 4 0 A 2 7 0 3 0 1 4 5 0 5 1 4 5
